TJM MSI MEG X870E GODLIKE, Motherboard

• Model: MSI MEG X870E GODLIKE
• Form Factor: E‑ATX
• Socket: AMD AM5
• Chipset: AMD X870E
• CPU Support: AMD Ryzen™ 9000 series (Zen 5) and backward compatible with AM5 CPUs
• Memory:
 – 4 × DDR5 DIMM slots
 – Dual-channel architecture
 – Up to 192 GB capacity
 – Supports DDR5‑9000+ (OC)
• Expansion Slots:
 – PCIe 5.0 x16 slots (multi‑GPU ready)
 – PCIe 5.0 M.2 slots with EZ Slide Shield Frozr
 – Additional PCIe 4.0 slots
• Storage:
 – Multiple PCIe 5.0 M.2 slots
 – PCIe 4.0 M.2 slots
 – 6 × SATA III ports
 – RAID support
• USB Ports:
 – USB4 (40 Gbps)
 – USB 3.2 Gen2x2 Type‑C
 – Multiple USB 3.2 Gen2/Gen1 Type‑A
• Networking:
 – 10G Super LAN + 2.5G LAN
 – Wi‑Fi 7
• Audio: High‑definition audio with premium codec
• Cooling & Power:
 – 24+2+1 phase VRM design with SPS DrMOS
 – Supplemental PCIe power connectors
 – Heatsinks with embedded crystal‑cut tempered glass
• Special Features:
 – Dynamic Dashboard III: 3.99‑inch full‑color LCD for real‑time monitoring and personalization
 – Dragon design with stereoscopic accents
 – Advanced overclocking tools and AI tuning support
• Dimensions: E‑ATX (extended ATX)
