TJM Cooler Master ELITE NEX 700W 80 White Non-Modular - Black

General

• Brand: Cooler Master

• Model: Elite NEX 700W

• Type: ATX Power Supply Unit (PSU)

• Color: Black

• Certification: 80 Plus White (basic efficiency rating)

• Form Factor: Standard ATX

Electrical Specifications

• Total Power Output: 700W

• Efficiency: ~80% at typical load

• Input Voltage: 100–240V AC, 50/60Hz

• Active PFC: Yes

• Hold‑up Time: ≥17 ms at full load

Cabling & Connectors

• Design: Non‑modular (fixed cables)

• Main Connector: 24‑pin ATX

• CPU Power: 1 × 8‑pin (4+4) EPS

• PCIe Power: 2 × 8‑pin (6+2) PCIe

• SATA Power: 6 × SATA connectors

• Peripheral (Molex): 3 × 4‑pin

• Floppy: 1 × FDD connector

Cooling & Noise

• Fan: 120 mm sleeve‑bearing cooling fan

• Noise Level: ~25–30 dBA under load

• Airflow: Optimized for stable cooling

Protection Features

• OVP (Over Voltage Protection)

• OPP (Over Power Protection)

• SCP (Short Circuit Protection)

• UVP (Under Voltage Protection)

Dimensions & Build

• Size: 150 × 140 × 86 mm

• Weight: ~1.5 kg

• Finish: Matte black housing

Package Contents

• Cooler Master Elite NEX 700W PSU × 1

• AC Power Cable × 1

• Mounting Screws × 1 set

• Quick Installation Guide × 1
